Filament Drying Protocol: A Lab-Grade Procedure for Each Material

Almost every filament ↗ is hygroscopic to some degree. Once moisture content rises past 0.2–0.5% by weight, prints develop the familiar symptoms: surface defects, weak layer adhesion, audible popping at the nozzle, and stringing that won’t tune out.

The fix is straightforward — heat and time. But the parameters matter. Too low a temperature wastes hours without removing moisture; too high deforms the spool or melts the filament into a fused mass. This guide is a reference protocol for the materials we handle most.

How Filament Absorbs Moisture

Filament polymer chains have polar sites that attract water molecules from atmospheric humidity. Absorption rate depends on:

Material chemistry: nylon and PVA are extremely hygroscopic; PLA and ABS are moderate; PETG is mild; polypropylene is almost not at all.
Humidity exposure: a sealed bag with desiccant maintains < 10% RH; an open spool in a humid garage can climb past 0.5% moisture in days.
Temperature: warmer ambient air can hold more water; storage in a warm humid environment is worst.
Surface area: a fresh spool with smooth winding absorbs slower than one that’s been used and now has loose loops exposed.

The result is that filament dries unevenly — outer layers lose moisture first; the inside of a 1kg spool can hold moisture days after the outside reads “dry.”

Symptoms of Wet Filament

In rough order of subtle to obvious:

Stringing that doesn’t respond to retraction tuning
Surface defects on outer walls — small bumps or pits
Weak interlayer adhesion (parts split along layer lines under modest load)
Audible popping or hissing at the nozzle during extrusion
Visible steam rising from the nozzle
Inconsistent extrusion width
Bridging failures

If you see signs 4–7, dry the filament before continuing. Signs 1–3 may suggest moisture but can also be calibration issues; verify with a temperature tower on a known-dry spool first.

Recommended Drying Equipment

In rough order of capability and cost:

Dedicated filament dryer: best choice. Sunlu S2/S4, Polymaker PolyDryer, eSun eBox, Creality dryer. Operating range 35–80°C. Most can print directly from the chamber, maintaining dry conditions during use.

Food dehydrator: workable. Cabela’s, Excalibur, and similar units have temperature controls in the 40–70°C range. Verify with a probe thermometer — many dehydrator dials are inaccurate by 10°C+.

Convection oven: workable for PLA only. Most home ovens cycle between off and 200°C+ even at low settings. The temperature overshoots will warp PLA spools. Use a probe thermometer in the oven; never use the dial setting alone.

Toaster oven: not recommended. Too much temperature variance for the time required.

Sun + sealed bag: an emergency-only option for mild PLA. Limited and inconsistent.

Drying Temperatures and Times by Material

These values assume a 1kg spool and an empty starting moisture content target.

Material	Temperature	Time	Notes
PLA	45°C	6–8 hours	Higher temps risk deforming the spool — 55°C is the upper limit.
PLA+ (toughened)	50°C	8–10 hours	Slightly slower than standard PLA due to additives.
PETG	65°C	6–8 hours	Tolerates higher temps; 70°C is safe for most brands.
ABS	70°C	6–8 hours	High glass transition allows aggressive drying.
ASA	70°C	6–8 hours	Same as ABS.
TPU (Shore A 95)	50°C	6 hours	Higher temps cause fusion of adjacent loops.
TPU (Shore A 85, softer)	45°C	6 hours	Soft TPU is at high risk of fusing.
PA (Nylon)	80°C	12–16 hours	Very hygroscopic; long drying time mandatory.
PA-CF (carbon-fiber nylon)	80°C	12–16 hours	Same as base nylon.
PC (Polycarbonate)	80°C	8–10 hours	Aggressive drying tolerable.
PVA (water-soluble support)	45°C	4–6 hours	Extremely hygroscopic; dry immediately before use.
HIPS	65°C	6–8 hours	Mild absorber; usually fine without drying.

Verification: Did It Actually Work?

Three methods, in increasing rigor:

Method 1: Test Print (subjective)

Print a 20mm vase or thin-walled tower right after drying. Compare to a known-dry baseline. If popping at the nozzle is gone and surfaces look smooth, the spool is dry enough.

Useful but not quantitative. Errors propagate if your “baseline” is itself slightly wet.

Method 2: Weight Change

Weigh the spool before and after drying. Wet filament will lose 5–20 grams in a 6-hour cycle. A second drying cycle that produces no further weight loss indicates dryness.

More rigorous but slower. The weight delta is small enough that a precise scale (0.1g resolution) is required.

Method 3: Probe Moisture Meter

Pin-style or capacitive moisture meters intended for wood or food show relative readings that correlate roughly with filament moisture. A “dry” wood reading on a spool is a reasonable proxy.

Coarse but fast. Use a single spool as a baseline reference and compare others against it.

Drying During Printing

For materials prone to re-absorbing moisture during long prints (nylon especially):

A dryer with a filament feed-through hole maintains drying while printing.
The Sunlu S4 holds four spools and feeds filament out the side; for AMS systems, the eSun eBox Pro feeds into the AMS chamber.
DIY: a sealed bin with PTFE port and silica desiccant works for hours-long prints.

Without active drying, nylon will re-absorb measurable moisture within 30 minutes of exposure to typical room humidity.

Storage Between Prints

For active rotation (used within a week): cardboard box of silica desiccant beads, sealed.

For long-term storage (weeks+): vacuum bag with desiccant. Most household food vacuum sealers work; mylar mylar bags rated for desiccant storage are ideal.

For valuable engineering filaments (PC, PA, PA-CF): always returned to a vacuum bag immediately after use. Treat them like camera film, not consumables.

Desiccant beads are reusable — recharge in the oven at 110°C until they change from saturated color back to dry color. Indicator beads (blue-when-dry, pink-when-saturated; orange/green variants for cobalt-free options) make this trivial.

Common Mistakes

Drying at room temperature for “longer time” doesn’t work. Below ~40°C, the absorbed water doesn’t migrate to the surface fast enough to evaporate.
Using a dehumidifier on the room has limited effect on the moisture already inside the spool. It only slows re-absorption.
Skipping the verification step leads to false confidence. A nominally dried spool may be dry on the outside but still wet inside.
Mixing wet and dry spools in storage equilibrates them all to the higher humidity level. Always separate.

Material-Specific Notes

Nylon (PA, PA-CF, PA-GF): drying every batch is mandatory. There is no acceptable “skip the drying” scenario. Nylon prints from a non-dried spool will be visibly defective and mechanically weak.

TPU: deceptive. Mild moisture often doesn’t show visible defects, but layer adhesion in tension suffers measurably. If you’re printing functional TPU parts, dry every batch.

PVA: dries fast, absorbs faster. Dry immediately before printing. Once exposed to air, PVA spools have hours, not days, of acceptable performance.

PLA: forgiving of mild moisture for cosmetic prints; significant moisture (signs 4+) requires drying before continuing.

PETG: mild absorber by default. Most spools work fine without drying unless they’ve been stored badly. Tested before assuming.

Cost-Benefit

A filament dryer pays for itself within months for any user printing more than a kilogram of nylon or PA per year. For users printing primarily PLA in a dry climate, the ROI is longer but the convenience of drying when needed is worth the modest cost.

The Sunlu S2 ($60) suffices for occasional drying. The Sunlu S4 ($120) is the sweet spot for users with multiple active spools or who want to dry while printing.

A Note on Filament Sensors

Some printers have filament-moisture sensors built in. They’re unreliable; they typically detect only severe moisture (signs 5+). Don’t rely on them; use the protocol above instead.

A consistent drying habit prevents most of the “my prints look bad and I don’t know why” hours that new users lose to invisible moisture. Treat it as routine, not exceptional.
